Pure Sine wave generator with LCD Display

Technical Specifications-Solar

INVERTER
UPS
MULTI-LOAD
INPUT VOLTAGE 160V – 270V 190V – 250V 170V – 250V
INPUT FREQUENCY 50 Hz 50Hz 50Hz
OUTPUT VOLTAGE 240+/-10% 230+/-5% 230+/-10%
CHANGE OVERTIME 10milli sec 3milli sec 3-4milli sec
I/P VOLTAGE CHARGING 140V-280V 140V-280V 140V-280V
INDICATIONS & ALARMS MAINS ON
INVERTER ON
BATTERY CHARGING BATTERY LOW
OVER LOAD
SHORT CIRCUIT

MAINS ON
INVERTER ON
BATTERY CHARGING BATTERY LOW
OVER LOAD
SHORT CIRCUIT

MAINS ON
INVERTER ON
BATTERY CHARGING BATTERY LOW
OVER LOAD
SHORT CIRCUIT
POWER FACTOR 0.8 0.8 0.8
ALARM NOISE LEVEL < 35 db at 1 meter < 35 db at 1 meter < 35 db at 1 meter
EFFICIENCY <90% <95% <85%
BATTERY TYPE





BATTERY BACK-UP


RECHARGING TIME

SEALED PLASTIC CONTAINER TUBULAR BATTERY
MAINT.. LESS



½ , 1,2,3,4 Hour


8 HOURS IN COMPLETELY DISCHARGED CONDITION
SEALED PP CONTAINER TUBULAR BATTERY
MAINT.. LESS




½ , 1,2,3,4 Hour


8 HOURS IN COMPLETELY DISCHARGED CONDITION
SEALED PLASTIC CONTAINER TUBULAR BATTERY
MAINT.. LESS



½ , 1,2,3,4 Hour


8 HOURS IN COMPLETELY DISCHARGED CONDITION
ON-LINE UPS (Computer Network)

SINGLE I/P – SINGLE O/P
THREE PHASE I/P –
SINGLE O/P
INPUT VOLTAGE 230 + / -10% 415 + / - 10%
FREQUENCY 50 Hz 50 Hz
OUTPUT VOLTAGE 230 + / -10% 230 + / - 10%
WAVE FORM SINE WAVE SINE WAVE
POWER FACTOR 0.8 0.8
EFFICIENCY <90% <90%
PROTECTIONS O/P OVER VOLTAGE
O/P UNDER VOLTAGE
BATTERY OVER CHARGE
BATTERY LOW
OVER LOAD / SHORT CIRCUIT
CHARGING CURRENT
O/P OVER VOLTAGE
O/P UNDER VOLTAGE
BATTERY OVER CHARGE
BATTERY LOW
OVER LOAD / SHORT CIRCUIT
CHARGING CURRENT
INDICATIONS MAINS ON
UPS ON
UPS TRIP
BATTERY LOW
OVER LOAD
LCD DISPLAY OPTIONAL
MAINS ON
UPS ON
UPS TRIP
BATTERY LOW
OVER LOAD
LCD DISPLAY OPTIONAL
INVERTER BYPASS

CHARGER

MANUAL SWITCH

AUTO BOOST cum SCR

MANUAL SWITCH

AUTO BOOST cum SCR

* Specification may change without any prior notice, due to our constant endeavor to improve the products.
